Generac 25kW Protector XG 3-Phase Standby Generator | XG02525CNAX

$17,149.00

Description

The Generac 25kW Light Commercial Protector XG Series 3-Phase Standby Generator (Model XG02525CNAX) provides reliable automatic backup power for commercial applications, delivering 25kW of rated power on both liquid propane and natural gas.

Powered by a 2.5-liter Generac engine operating at a quiet 1,800 RPM, the XG02525CNAX features a liquid-cooled system with a cast iron sleeve for extended engine life, a synchronous self-excited 12-lead alternator, and solid-state automatic voltage regulation. The generator includes low oil shutdown protection and utilizes the controller for overcurrent protection.

Designed for outdoor commercial standby installations, the unit features a durable aluminum enclosure and operates at an ultra-quiet 58 dBA in Quiet-Test / Low Idle mode and 64 dBA under normal load. The system is UL 2200 listed and comes with a Generac 5-Year / 2,000-Hour Limited Warranty for both consumer and commercial applications.

Key Features

25kW Standby Power (Natural Gas & Liquid Propane)
3-Phase Configurable Voltage Output (208V / 240V / 480V)
2.5-Liter Generac Liquid-Cooled Engine with Cast Iron Sleeve
1,800 RPM Low-Speed Engine for Quiet & Long-Life Operation
Synchronous Self-Excited 12-Lead Alternator
Automatic Voltage Regulation
Quiet-Test™ / Low Idle Self-Test Mode (58 dBA)
Quiet 64 dBA Sound Rating Under Normal Load
Dual-Fuel Capability (Natural Gas or Liquid Propane)
Low Oil Shutdown Protection
Corrosion-Resistant Aluminum Enclosure
UL 2200 Listed Certification
USA Engineered and Built
Transfer Switch Sold Separately
5-Year / 2,000-Hour Limited Warranty

Specifications

Brand	Generac
Manufacturer	Generac Power Systems
Series	Protector XG Series
Model	XG02525CNAX
MPN	XG02525CNAX
Product Type	Light Commercial Standby Generator
Rated Power - LP	25 kW
Rated Power - Natural Gas	25 kW
Phase	3-Phase Configurable
Rated Current	104 Amps @ 208V \| 90 Amps @ 240V \| 45 Amps @ 480V
Voltage	3-Phase Configurable (208V / 240V / 480V)
Frequency	60 Hz
A/C Ton Rating	5 Ton
Engine Brand	Generac
Engine Displacement	2.5 Liter
Engine Speed	1,800 RPM
Cast Iron Sleeve	Yes
Cooling System	Liquid Cooled
Fuel Type	Natural Gas or Liquid Propane
NG Consumption @ Full Load	452 ft³/hr
NG Consumption @ Half Load	244 ft³/hr
LP Consumption @ Full Load	2.6 gal/hr
LP Consumption @ Half Load	1.2 gal/hr
Alternator	Synchronous Self-Excited 12-Lead
Automatic Voltage Regulation	Yes
Sound Level	58 dBA Quiet Test / Low Idle \| 64 dBA Normal Load
Starting System	Automatic Start
Low Oil Protection	Low Oil Shutdown
Mainline Breaker	Optional Accessory (Controller Provides Overcurrent Protection)
Enclosure	Aluminum
UL Listed	UL 2200
USA Engineered and Built	Yes
Mounting Pad	Requires Prepared Site
Dimensions	66.6 L × 32.6 W × 40.7 H in.
Weight	1,120 lb.
Battery	Flooded Acid, 12-Volt, Group 26, 525 CCA
Warranty	Generac 5-Year / 2,000-Hour Limited Warranty
