Generac 22kW Next Gen Generator Home Standby with 200-Amp SE Rated Automatic Transfer Switch | 7325

$7,229.00

Description

The Generac 22kW Next Gen Home Standby Generator (Model 7325) provides reliable automatic backup power for residential applications, delivering 22kW on natural gas and 21kW on liquid propane.

The system includes a 200-Amp Automatic Transfer Switch and Generac's Power Zone Controller for automatic power transfer and enhanced generator control.

With Mobile Link oil level monitoring, automatic operation, improved connectivity, an air-cooled 997cc V-Twin engine, and a 5-Year Limited Warranty, the Generac 7325 is designed for dependable residential standby power.

Key Features

22kW Standby Power (Natural Gas) & 21kW (Liquid Propane)
200-Amp Automatic Transfer Switch (Whole-Home Application)
Next Gen Series Standby Design
Automatic Operation On Utility Interruption
Mobile Link Monitoring with Oil Level Tracking
Low Oil Shutdown Protection
Generac G-Force 1000 Engine (997cc V-Twin)
Electronic Engine Control
Outdoor-Rated Aluminum Enclosure
Automatic Voltage Regulation
Dual Fuel Operation (Natural Gas or Liquid Propane)
5-Year Limited Consumer & Commercial Warranty

Specifications

Model Number	7325
Manufacturer	Generac
Made in USA	Yes
Rated Watts	22 kW
Rated Amps	92 Amps
Voltage	120/240 Volts
A/C Ton Rating	5-Ton
Enclosure	Aluminum
UL Listed	UL 2200
Decibel Rating	67 dBA at Normal Load
Type	Standby Generator
Series Name	Next Gen
Starting System	Automatic
Low Oil Alert	Low Oil Shutdown
Oil Level Monitoring	Via Mobile Link
Mainline Breaker	100 Amps
Battery	12-Volt AGM Group BTX20L, 310 CCA
Weight	451 Pounds
Dimensions	46.4 W × 26.3 D × 30.7 H inches
Consumer Warranty	Generac 5-Year Limited Warranty
Commercial Warranty	Generac 5-Year Limited Warranty

Engine

Engine Brand	Generac G-Force 1000
Engine Size	997cc V-Twin
Engine RPM	3,600 RPM
Cast Iron Sleeve	Yes
Cooling System	Air Cooled

Alternator

Alternator Type	2-Pole Revolving Field
Frequency	60 Hertz
Automatic Voltage Regulation	Yes

Fuel

Fuel Type	Natural Gas or Propane
Fuel Gauge	No
NG Power Capacity	22 kW
LP Power Capacity	21 kW
NG Consumption @ Full Load	311 Cubic Feet per Hour
NG Consumption @ Half Load	221 Cubic Feet per Hour
LP Consumption @ Full Load	3.71 Gallons per Hour
LP Consumption @ Half Load	2.45 Gallons per Hour
